NMEA 2000, Micro, Metal Non-shielded, 4A, 05 pins, Female Connector, Female Contact, Hexagonal, PG9, Screw Thread, Solder, Receptacle With Wire, Front Fastened, Length 300mm, PVC, 18 AWG, IP68 Unmated
無庫存情況下, 工廠標準前置時間8~10週。
型號: MC-05PFFS-SF8001
| 數量 | 價格 |
|---|---|
| 1 ~ 99 | NT$ 360 (USD$ 12.41) |
| 100 ~ 499 | NT$ 240 (USD$ 8.28) |
| 500 以上 | NT$ 212 (USD$ 7.31) |
| 商品規格 | |
|---|---|
| 額定電流 | 4A |
| 線徑 | 18 AWG |
| 芯線/線材長度 | 300 |
| 鎖合方式 | Front |
| 板端螺母牙規 | PG9 |
| 線徑 (mm) | N/A |
| 鹽水噴霧測試 | 48h |
| 額定電壓 | 60V |
| 端子加工方式 | Solder |
| 防水等級 | IP68 |
| 接合方式 | Screw Thread |
| 背板樣式 / 出線方式 | Hexagonal |
| 端子 (公/母) | Female |
| 位置數 | 05 |
| 連接器類型 | Receptacle With Wires |
| 板厚 | 4.50 |
| 連接器材質 | MetalNon-shielded |
